R56L - 4G Plug & Play OBD GPS Tracker

SEEWORLD R56L 4G Plug & Play OBD GPS Tracker:

  • Plug & Play Feature. The SEEWORLD R56L car GPS tracker is an easy-to-install sophisticated OBD interface GPS positioning and tracking device. By connecting this OBD GPS tracker to your car’s OBD-II port, you can avoid time-consuming installation; there’s also no need to worry about unexpected power shortages, and it delivers 24 hours of continuous GPS tracking and monitoring for your vehicle.
  • Smart Alarm. The driving route, stay length, driving speed and direction, and other information are automatically saved in our WhatsGPS platform (up to 6 months). The Geo-Fence feature allows you to restrict the OBD GPS tracker’s movement inside a district and receive notifications if it leaves it. Other alert features include rapid acceleration/deceleration, collision warning, and more.

Application:

  • Bus management
  • Smart school buses
  • C-end users
  • Fleet management companies
  • Official car management industries.

Product Parameters

Additional information

GSM RF Chip

SIMCOM A7670

GSM Canal

A7670C: China
LTE-FDD B1/B3/B5/B8
LTE-TDD 34/B38/B39/B40/B41
GSM 900/1800 MHz

A7670E: Europe
LTE-FDD B1/B3/B5/B7/B8/B20
GSM 900/1800 MHz

A7670SA: Latin
LTE-FDD B1/B2/B3/B4/B5/B7/B8/B28/B66
GSM 850/900/1800/1900 MHz

GPRS Clase

Class 12,TCP/IP

Communication Protocol

TCP

Device Memory

16Mb

Phase Error

<10°

Maximum output

32±3 dBm

Maximum Frequency Error

±0.1 ppm

GPS Chipset

AT6558R

Positioning Mode

BDS/GPS/GNSS/LBS

Frequency

L1, 1575.42mHZ C/A Code

Number of Channels

72

Positioning Accuracy

<10 meters

Tracking Sensitivity

-162 dBm

Capture Sensitivity

-148 dBm

Positioning Time

Average fast start <2s
Average warm start <28s
Average cold start <38s

Device Agreement

GT06 Default Protocol

Operating Voltage Range

9-90 V

Work stream

50MA/12V

Resting current

5 mA

Battery

100 mAh

Continuous Working Time

20 mins

Continuous Steady State Battery Life

4h

Blind Spot Tracking Point Storage Capacity

600

Operating Temperature

-30°C ~ +80°C

Working Humidity

35% ~ 80%

Dimensions

L54MM*W34MM*H32MM

Weight

39g

Waterproof Grade

IP65

Product Functions

Vibration Alarm

With built-in vibration sensor, an alarm will be sent immediately when the vehicle has abnormal vibration.

GEO-Fence Alarm

The owner can customize the GEO fence, and when the vehicle is driving in or out of the fence, it will send an alarm.

Driving Behavior Analysis

*Harsh acceleration *Harsh braking *Harsh cornering *Collision

Over-speed Alarm

You'll be notified when vehicle speed is higher than preset value.

Multiple Alerts

Instant alerts for atypical events such as abnormal vibration, speeding, power-off, geo-fence in/out, etc.

Power Off Alarm

When the car is power-off it will send an alarm.

File Download
