S06U - 2G High Precision Wholesale GPS Tracking Device for Work Vehicles with GEO-Fence Alarm (Black)

S06U - 2G High Precision Wholesale GPS Tracking Device for Work Vehicles with GEO-Fence Alarm (Black)

S06U bulk buying GPS tracking terminal comes with rich functions and a wide range of applications. This 2G black work vehicle tracking equipment adopts an MTK2503D chip and supports GPS, BeiDou, Galileo, and GLONASS satellite systems. In addition to supporting satellite positioning, the tracking equipment also supports single-base station and multi-base station positioning.

SEEWORLD S06U wholesale vehicle GPS tracker not only supports satellite positioning but also supports single base station and multi-base station positioning.

S06U comes with built-in high sensitivity GPS and GSM antenna, supports real-time tracking, history playback, blind zone re-recording, oil cut-off, over speed alarm, GEO fence alarm, mileage statistics, ACC detection, power failure alarm, etc., making it one of the hot sales for our company.

Integrating a self-developed hardware monitoring circuit makes this 2G high precision GPS locator work reliably and stably for a long time, and can automatically recover when an abnormality occurs.

Features of this S06U wholesale GPS tracker:

  • GEO-fence.
  • Power cut-off alarm. When the electricity supply of the device is cut off, it will activate the cut-off alarm.
  • Vibration alarm(default OFF) When the work vehicle vibrates several times, the vibration alarm will be triggered. If no ignition after 3 minutes (ACC OFF), the device will send a vibration alarm message immediately.
  • Supports all deployed and upcoming global navigation satellite systems GPS, BeiDou, Galileo, and GLONASS.
  • Adopt a high-temperature, safe, and explosion-proof rechargeable lithium cobalt oxide battery.
  • Built-in hardware monitoring circuit, automatic recovery of abnormal state.

This S06U 2G hardwired tracker is one of the best GPS trackers for work vehicles. It can also be widely used in the following situations and industries:

  • Private anti-theft
  • Taxi management
  • Car rental companies
  • Logistics transportation

Additional information

Weight 0.08 kg
Dimensions 9.8 × 5.2 × 1.5 cm
GPS

SIRF Star III

GPRS

Class 12,TCP/IP build in GSM Module

GSM

850/900/1800/1900Mhz

Battery

500mAh

Working times

5 hours

Chip specification

Ublox M8030

Positioning accuracy

<5 meters

Support input voltage range

6-30V(<30mA)

TTFF(Open Sky)

Avg.hot start ≤1s ; Avg.cold start ≤30s

Working temperature:

-20℃ ~ +70℃

Data storage quantity

1000

Voltage input range

5-36 VDC


GEO fence alarm:Set fence alarms with SMS commands to provide a safety net for your vehicle or other assets.


Remote oil cut:The system sends a power-off command, and the relay disconnects the power of the ignition device to achieve vehicle stall.


ACC detection:The vehicle is connected to the ACC line and users can view the vehicle status on the system. ACC on, on behalf of vehicle ignition, ACC off, on behalf of the vehicle stall.


Overspeed alarm:When the speed of the vehicle exceeds the overspeed speed value set by the platform, the overspeed alarm is triggered, and the device will send an alarm signal to the GPS monitoring platform.


Power Off alarm:If the GPS Tracker encounters a forced damage, such as cutting a cable, the locator will push an alarm message for the power failure alarm to the system.

Vibration alarm
Vibration alarm:After the device enters the armed mode,the device detects the vehicle vibration,triggers the vibration alarm and sends an alarm signal to the GPS monitoring platform.

Remote listening
Remote listening:Send the SMS code to the mobile phone number bound to the device, and the device can be pulled back to enable remote listening.

SOS alarm
SOS alarm:As long as you press the button,the SOS alarm will be triggered,and the alarm signal will be sent to the GPS monitoring background.
