S208L 4G Truck GPS Tracker - Hardwired Asset GPS Tracking Device for Trucking Companies with Remote Fuel/Oil Cut Off

S208L 4G Truck GPS Tracker - Hardwired Asset GPS Tracking Device for Trucking Companies with Remote Fuel/Oil Cut Off

Rated 0 out of 5
(be the first to review)

S208L is a 4G CAT4 vehicle tracker for trucking companies that supports GPS/BDS dual positioning technology. It integrates real-time positioning, remote recording, remote flame-out, fuel report, multiple abnormal alarms, and other functions in one. It’s suitable for truck/fleet management, cold chain transportation, and so on.

Seeworld S208L truck tracker delivers superior fleet truck tracking information based on the most up-to-date and precise GPS tracking technology. This 4G hardwired GPS tracker boasts a wide range of alert systems, real-time tracking, location information display via (Android / iOS APP, Web / WAP) platform, positioning precision of up to 3 meters.

With the remote fuel/oil cut-off function, you can control your car, cut the oil and fuel electrically and protect your car safely. When your car vibrates the built-in vibration sensor will send you an SMS alarm. And you can get alarmed when the vehicle is out of the set speed.

Feature of this GPS tracker for trucking companies:

  • Vibration alarm
  • Speed Alarm
  • ACC Alarm
  • Remote oil and electricity control
  • Power-off alarm. When the terminal power supply is cut off, a power-off alarm will be triggered, and the terminal will send an alarm message to the center number and service platform.
  • More…

This truck GPS tracking device can be widely used in:

  • Engineering vehicle management
  • Cold chain vehicle management
  • Fleet management
  • Special vehicle dispatch
  • Transporting truck dispatch
  • Working vehicles

Additional information

Weight 0.168 kg
Dimensions 10.1 × 6.7 × 2.4 cm
GSM RF chip

EC25-AUX (Latin America)

GSM channel

508(3G)E:GSM 850/900/1800 /1900 UMTS 850/900/1900/2100
508(3G)A:850/1900MHz@UMTS 850/900/1800/1900MHzQGSM
508(3G)-T:900/210омHz@UMTS 900/1800MHz@GSM

GPRS class

lass 12, TСР/IР

Communication protocol

TCP

Body memory

16Mbit

Phase error

RMSPE-5,PPE<20

Maximum output

GSM900:28.5+2dBm GSM800:26.5+2dBm

Maximum frequency error

±0.1ppm

GPS chipset

AT6558R

Positioning mode

GPS/BDS/GLONASS

Frequency

1575.42MHZ , 1561.10MHZ

Number of channel

35

Positioning accuracy

<3M

Tracking sensitivity

-163dBm

Capture sensitivity

-47dBm

Positioning time

Avg. hot start <1s
Avg. warm start <28s

Device agreement

Private agreement (default) /808protocol

Operating voltage range

8-50VDC/50mA-100mA

Battery

500mAh

Continuous Working Time

5h

Storage capacity o f blind spot track points

10000

Operating temperature

-30℃-+75℃

Waterproof and dust grade

IP65

Device size

L101.0mm*W50.0mm*L24.0mm

Weight

168g

Standard Packing

Main unit,GPS/GSM Antenna,Power cable,I/O cable,RS232 cable,Relay

Oil detection

When the tracker senses a sudden change in fuel, it will sound an alarm.

Remote Cut Off Fuel and Electricity

Owner can remotely make the car flame out.

Temperature check

When the tracker senses a sudden change in temperature, it will sound an alarm.

SOS Alarm

When the driver is facing accidents or abnormal situations, he/she can use it to send an sOS alarm.

Vibration Alarm

When the car has abnormal vibration it will send an alamm.

Remote Voice Listening (Optional )

The mobile phone dials the locator card number, and the locator automatically answers the live voice
