SEEWORLD R11 Vehicle GPS Tracker - Driving Behavior Analysis

R11 - 2021 New Arrival 2G GPS Tracking Device with Driving Behavior Analysis

Rated 0 out of 5
(be the first to review)
SEEWORLD R11 is a 2G multi-functional positioning terminal, supporting GPS + BeiDou + LBS + WiFi (optional) positioning. In addition to the basic functions, such as support for ACC detection, fuel cut-off control and vibration alarm, the R11’s biggest highlight is that it supports driving behavior analysis, with built-in 10-level adjustable vibration sensor sensitivity, which supports rapid acceleration, rapid deceleration, sharp turn alarm and statistical analysis. It also supports the automatic recovery when the device is abnormal.
R11 is suitable for auto finance, leasing, mortgage and other fleet management.
1. ACC Detection
2. Driving Behavior Analysis
3. Remote Fuel Cut-off and Power Control
4. Vibration Alarm
5. Low Battery Alarm
6. GEO-Fence Alarm



Additional information

GSM RF chip

HS8269

GSM channel

850/900/1800/1900MHz

GPRS class

Class 12,TCP/IP

Communication protocol

TCP

Body memory

4MB

Phase error

<10°

Maximum output

32±3dBm

Maximum frequency error

±0.1ppm

GPS chipset

AT6558R

Positioning mode

GPS+BDS+LBS+Wifi (Optional)

Frequency

L1,1575.42Mhz C/A code

Number of channels

72

Positioning accuracy

<10 meters

Tracking sensitivity

-162dBm

Capture sensitivity

-148dBm

Positioning time

Avg.hot start <2s
Avg.warm Start <28s
Avg.cold start <38s

Device agreement

GTO6/GTO6N

Operating voltage range

9-90V

Working current

25mA/12V

Quiescent current

2.5mA

Battery

100mA

Continuous working time

40minute

Continuous stationary battery life

24Hour

Storage capacity of blind spot track points

400

Operating temperature

-30℃~+80℃

Working humidity

35%~80%

Dimensions

L80mm*W28mm*H14mm

Waterproof and dustproof grade

IP65

ACC Detection

Owners can use ACC detection to see if their vehicle has ignition

Driving Behavior Analysis

The device supports rapid acceleration, rapid deceleration, sharp turn alarm and statistical analysis.

Remote Fuel Cut-off and Power Control

Owner can remotely control the vehicle by disconnecting the fuel and electricity.

Vibration Alarm

With built-in vibration sensor, an alarm will be sent immediately when the vehicle has abnormal vibration.

Low Battery Alarm

Alerts immediately when the vehicle is in a low battery condition.

GEO-Fence Alarm

Owners can customize the division of the electronic fence, and when the vehicle drives into or out of the electronic fence, the locator will immediately alarm.
